Kyosho Autoscale Nissan Silvia K S13 Body

Autoscale series body of the Nissan Silvia K's (S13) model in Warm White (white) , manufactured by Kyosho, for the Mini-Z Racer.

What does this Autoscale body kit for the Nissan Silvia K's S13 model include?

Along with the body of this model, the wheels (for the AWD 4x4 version of the Mini-Z Racer) are included, as well as the front tab that must be used to mount the body onto the racing chassis. The wheels and body are attached to a dummy chassis that serves only as a display for the body and has no other function.

The bodywork is supplied fully assembled and painted, attached to the "dummy" chassis, inside a clear plastic box perfect for collecting.

What are the characteristics of this body style?

The Autoscale Nissan Silvia S13 K's body kit uses four narrow (8mm) wheels with a +0 offset. As previously mentioned, these wheels, due to their mounting type, can only be fitted to AWD (4x4) chassis, whether from Kyosho or other manufacturers.

In this body style the wheelbase is 90mm, therefore, we will have to adjust our chassis to this wheelbase.

Another feature of this body is the option to install LED lights both front and rear. The front body has a total of six holes for 3mm LEDs, three in each of the two headlights. The rear has four holes for red LEDs, two in each taillight.

The lighting kit (not included with this body) for the Kyosho Mini-Z Sports that we will need to use in this case can be found on this website and has the reference: MZW429R .

On which chassis models can I use the Nissan Silvia K's S13 body?

As with all bodies for the Kyosho Mini-Z Racer, this body features a front mounting bracket and two L-shaped brackets for the side mounts (one on each side). It is initially designed to be mounted on the Kyosho MA020 chassis and its variants MA020S, MA020VE, MA020VE PRO, and MA010, provided the chassis is configured with a 90mm wheelbase and the narrow front axle is fitted.

Therefore, we can also mount this body on the Atomic AMZ and BZ chassis, as long as they are adapted to the 90mm wheelbase.
